Shandong Luxin New Material Co., Ltd.
2 Years
| Ask Lasest Price | |
| Brand Name : | Luxin |
| Model Number : | TG2 |
| Supply Ability : | 10000 Square Meter/Square Meters per Day |
| Price : | $1.49 - $1.92/square meters |
item | value |
Warranty | More than 5 years |
After-sale Service | Online technical support, Free spare parts |
Project Solution Capability | total solution for projects |
Design Style | Modern |
Place of Origin | China |
Shandong | |
Brand Name | Luxin |
Model Number | TG2 |
Product name | 3D composite drainage network |
Application | Landfill |
Material | High-density Polyethylene Plastic |
Keyword | Drainage |
Color | Black White |
Usage | Draingae System |
Function | Water Draining |
Length | 50m |
Width | 4m |
Certificate | ISO9001 |
Specification and Model | 1200g | 1360g | 1520g | 1680g | |||
Mass per unit area of Three-dimensional Composite Drainage Geonet
（g/㎡） | ≥1200 | ≥1360 | ≥1520 | ≥1680 | |||
Thickness of Three-dimensional Composite Drainage Geonet（mm） | ≥8.2 | ≥9.2 | ≥10.2 | ≥11.2 | |||
Longitudinal tensile strength of Three-dimensional Composite
Drainage Geonet（kN/m） | ≥16.0 | ||||||
Transmissivity of Three-dimensional Composite Drainage Geonet （㎡/s） | ≥1.2×10-4 | ||||||
Peel strength between drainage geonet and geotextile（kN/m） | ≥0.3 | ||||||
Thickness of drainage geonet（mm） | ≥5.0 | ≥6.0 | ≥7.0 | ≥8.0 | |||
Longitudinal tensile strength of geonet（kN/m） | ≥8.0 | ||||||
Mass per unit area of geotextile（g/㎡） | ≥200 | ||||||
Normal permeability coefficient of geotextile（cm/s） | ≥0.3 | ||||||
Width of Three-dimensional Composite Drainage Geonet（m） | 4 | ||||||
Length of Three-dimensional Composite Drainage Geonet（m） | 30 | ||||||
|
|
